超微主板 X13DGU 支持第四代至强可扩展 LGA4677

超微主板 X13DGU 支持第四代至强可扩展 LGA4677

Key Features

4th Gen Intel Xeon Scalable processors, Dual Sockets LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP
Support HBM and CXL
Intel C741? Chipset
Up to 8TB 3DS ECC RDIMM, DDR5-4800MHz in 32 DIMM slots
12 PCIe 5.0 MCIO x8
Dual LAN with Intel X710 10GbE
1 VGA port
2 hybrid M.2
2 USB 3.0

Product SKUs
MBD-X13DGU

Physical Stats
Form Factor	Proprietary
Dimension	14.29" x 17.32" (36.3cm x 43.99cm)

Processor
CPU	4th Gen Intel Xeon Scalable processors Dual Socket LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP SP XCC, SP MCC, and MAX Series (HBM) SKUs are supported
Core	Up to 60 cores

System Memory
Memory Capacity	32 DIMM slots Up to 8TB 3DS ECC RDIMM, DDR5-4800MHz
Memory Type	4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 4400MT/s (2DPC)
DIMM Sizes	16GB, 32GB, 64GB, 128GB, 256GB RDIMM: 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage	1.1V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)

0

0

关联内容

On-Board Devices
Chipset	Intel C741
SATA	Intel C741 controller for 10 SATA3 ports
Network Controllers	N/A
