超微准系统主板 X12DDW-A6 支持至强第三代 LGA4189

超微准系统主板 X12DDW-A6 支持至强第三代 LGA4189

Key Features

3rd Gen Intel Xeon Scalable processors
Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s

Intel C621A

Up to 4TB RDIMM, DDR4-3200MHz; Up to 4TB LRDIMM, DDR4-3200MHz
Up to 4TB Intel Optane? Persistent Memory 200 Series, DDR4-3200MHz (OC), in 16 DIMM slots

1 PCIe 4.0 x16 Left Riser Slot,
1 PCIe 4.0 x16 Right Riser Slot,
2 PCIe 4.0 x16 Center Right Hand Slot,
8 PCIe 4.0 NVMe Internal Port(s)
M.2 Interface: 2 PCIe 2.0 x1
M.2 Form Factor: 2260/2280
M.2 Key: M-Key
2 PCIe 4.0 x16, AIOM slots Superset of OCP 3.0 Expansion

Intel C621A controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
1 VGA D-Sub Connector port
AIOM for LAN

Product SKUs
MBD-X12DDW-A6

Physical Stats
Form Factor	Proprietary WIO
Dimension	12.288" x 13.404" (31.21cm x 34.05cm)

Processor
CPU	3rd Gen Intel Xeon Scalable processors Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Core	Up to 40 cores

System Memory
Memory Capacity	16 DIMM slots Up to 4TB Intel Optane? Persistent Memory 200 Series, DDR4-3200MHz Up to 4TB ECC LRDIMM, DDR4-3200MHz; Up to 4TB ECC RDIMM, DDR4-3200MHz
Memory Type	3200/2933/2666 MT/s ECC DDR4 LRDIMM, RDIMM
DIMM Sizes	16GB, 32GB, 64GB, 128GB, 256GB LRDIMM: 16GB, 32GB, 64GB, 128GB, 256GB RDIMM: 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage	1.2V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)

On-Board Devices
Chipset	Intel C621A
SATA	Intel C621A controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
IPMI	ASPEED AST2600 BMC
Graphics	1 ASPEED AST2600 BMC port(s)
Network Controllers	AIOM for LAN
